metal plate small laser cutter , small laser metal cutting machine 60m / min

Mahsulot tafsilotlari

Sertifikatlash: ISO9001: 2008

To'lov va etkazib berish shartlari:

Minimal buyurtma miqdori: 1 dona

Narxi: muzokaralar

Paket tafsilotlari: yog'och quti

Yetkazib berish muddati: 7-15 kun

Ta'minot qobiliyati: oyiga 2000 dona

Mahsulotning batafsil tavsifi

Mahsulot nomi:	Fiber lazerni kesish mashinasi	Lazer kuchi:	500w / 800w
Ish maydoni:	500 * 500 mm	Maksimal harakatlanish tezligi:	60m / min
Joylashtirish aniqligi:	± 0.01-0.03	Powe ta'minoti:	3 × 380V ± 10% 220V ± 10%
Paket:	Yog'och quti	Kafolat:	1 yil

Mahsulot tavsifi

nozik lazerni kesish mashinasi RISE LASER tomonidan ishlab chiqilgan va qilingan. Yupqa qatlamli metallni qo'llash uchun etakchi lazer texnologiyasi bilan qabul qilingan. Mashina marmar va Cypcut lazerni kesish tizimi bilan birlashtirilgan. Integratsiyalashgan dizayni, ikki tomonlama gantry chiziqli motorli haydash tizimi, do'stona interfeys va uzoq muddatli barqaror ishlash.

Asosiy xususiyatlari

1. Easy to operate: Adopted world’s leading technology EtherCAT bus USA cnc laser cutting system, very easy to operate;
2. Safe and compact structure: small size, very suitable for small and medium factories processing production;
3. High efficient and high speed: adopted double drive liner motor drive system, effectively improve the cutting accuracy and production efficiency;
4. Fiber laser source: adopted Maxphotonics laser source, which is the first domestic brand of the stable and reliable medium power laser source;
5. Precision cutting: adopted Swiss RAYTOOLS professional laser cutting head, to ensure the best cutting results;
6. Stable and durable: the machine tool is adopted granite marble, can keep shape and is high stable, which can effectively eliminate the shock generated by the high speed cutting processing;
7. Anti-corrosion, wear-resistant: the transmission parts is free maintenance, can cut corrosive materials.

Konfiguratsiya

^#	^Mahsulot	^{Texnik xususiyatlari}	^Tovar	^Eslatma
¹	^{Lazer manbai}	^800W	^Maxfotonika
²	^{chiziqli vosita}
³	^{Optik panjara}	^{piksellar soni 0,5 mkm}	^Ispaniya
⁴	^Haydovchi		^servotronix
⁵	^{Z o'qi Vintli modullar guruhi}
⁶	^{Lazerni kesish boshi}	^BT230
⁷	^{Nozik chiziqli qo'llanma rayi}		^Hiwin
⁸	^Marmar	^{18001350200}	^Shandong
⁹	^{Organ qoplami}	^Standart
¹⁰	^{Ishlov berish materiallari}	^Standart		^{aviatsiya alyuminiy qotishmasi}

Parametr

^{Ish hajmi}		^{500 × 500 (mm)}
^{Maks. Tezlashtirish}		^1,2g
^{X AXIS}	^{Maks. Harakat tezligi}	^{60m / min}
	^Yo'l	^{500 mm}
	^{Joylashtirish aniqligi}	^{± 0,01 mm}
	^{Takrorlashning aniqligi}	^{± 0,004 mm}
^{Y AXIS}	^{Maks. Harakat tezligi}	^{60m / min}
	^Yo'l	^{500 mm}
	^{Joylashtirish aniqligi}	^{± 0,01 mm}
	^{Takrorlashning aniqligi}	^{± 0,004 mm}
^{Z AXIS}	^Yo'l	^{100 mm}

Ish holati

¹	^{Ish harorati}	^{-10 ℃ ～ 45 ℃}
²	^{Nisbiy havoning namligi}	^{＜ 90% kondensator yo'q}
³	^{Atrof muhit}	^{Yaxshi shamollatish, tebranish yo'q}
⁴	^{Quvvatlantirish manbai}	^{3 × 380V ± 10% 220V ± 10%}
⁵	^{Quvvat chastotasi}	^50Hz

Application of Precision Fiber Laser Cutting Machine

Suitable for carbon steel ,mild steel,SS ,aluminum alloy plate and copper plate and other metal.It is suitable for medium and thin thickness material processing.
Plastmassa ishlov berish, aviatsiya, aerokosmik, elektronika, elektr jihozlari, trubka qismlari, avtomobil, oziq-ovqat mashinalari, to'qimachilik mashinalari, muhandislik mashinalari, nozik qismlar, kemalar, metallurgiya uskunalari, liftlar, maishiy texnika, plastmassa ishlov berish, oshxona anjomlari va jihozlari qo'llaniladi. , hunarmandchilik sovg'alari, asboblarni qayta ishlash, bezatish, reklama, metallni qayta ishlash va boshqa ishlab chiqarish sohalari.
